Horizontal Pressure Steam Sterilizer CD-YDA series
Horizontal Pressure Steam Sterilizer CD-YDA series

The horizontal autoclave, which adopt the way of gravity exchange to release the cold air from the chamber more completely to ensure the reliable sterilization.The control system automatically adjust the steam inlet and outlet according to chamber temperature during sterilizing. This unit is an ideal equipment for clinics, scientific research institutes and other organizations to sterilize surgical instruments, fabric glassed, and the culture media etc.

86-15688870591
cedric@cedriccn.com
Description

图层 8


Product Features:

·Automatically controlled the sterilizing process, easy to operate.

·With drying function,suitable for the medical dressing drying.

·With over-temperature,over-pressure auto-protect.

·The door can not be open until the pressure in the chamber is reduced to 0.027MPa.And the unit can not be started on if the door doesn't close well.

·The safety valve will be open automatically when the inner pressure over 0.24MPa and the steam would be exhausted the water tank.

·Automatically cut off the power if the water-lack happened, and alarm at the meanwhile.

·The chamber of the sterilizer is made of stainless steel.

·The cycle cannot be started if the door is not sealed. Once the cycle is started and running, the sealed door is locked and cannot be opened to ensure operational safety.


Product Specification:

Model

CD-150YDA

CD-200YDA

CD-280YDA

CD-400YDA

CD-500YDA

Disinfection Tank

φ440*1000mm

φ515*1000mm

φ600*1000mm

Φ700*1100mm

Φ700*1300mm

Capacity

150L

200L

280L

400L

500L

Working Pressure

0.25MPa

Working Temp.

138℃

Time of Sterilization

0-60 min

Time of Drying

0-60 min

Heat Average

≤±2℃

Power

9KW/380V 50Hz

9KW/380V 50Hz

12KW/380V 50Hz

15KW/380V 50Hz

15KW/380V 50Hz

Dimension

1350*600*1520

1400*670*1650

1400*770*1780

1430*880*1830

1800*900*1820

Packing Size(mm)

1560*750*1850

1560*820*1930

1680*920*1950

1600*1050*2050

1850*1050*2050

G.W/N.W

320/278 KG

378/318 KG

465/391 KG

530/456 KG

627/540 KG
