1. Adopt 1200 bars/mm high-performance grating. The new light source control system makes the instrument light source switching faster.2. Accurate 2nm bandwidth makes the test data more accurate. Use imported long-life light sources to reduce the consumption of users' consumables.3. The unique wavelength control system makes the wavelength accuracy higher. Improved optical system to make the test more accurate.4. Use imported photoelectric converters to make the instrument more sensitive.
86-175-5409-3886
cedric@cedriccn.com
Specification:
Model | C-UV759 |
Wavelength range | 190-1100nm |
Wavelength accuracy | ±0.3nm |
Wavelength repeatability | 0.1nm |
Spectral bandwidth | 1.8nm |
Transmission ratio accuracy | ±0.3%T |
Transmission repeatability | 0.1%T |
Baseline straightness | 0.001A/h |
Photometric range | -3-3A, 0-200%T, 0-9999C |
Stray light | 0.05%T@220nm/360nm |
Stability | ±0.001A/h@500nm |
Display method | 128×64 dot matrix LCD display |
RS232 communication | USB interface |
Printer | Optional |
Automatic eight-link color pool | Optional |
Optical system | Dual beam proportional detection |
Noise level | ±0.001A/2min@500nm |
