The product features a cold-rolled steel shell with a sprayed plastic coating and a stainless steel inner liner. It employs bottom resistance wire heating and air circulation through a fan, which can be turned off for natural convection. Equipped with an LED digital PID temperature controller, it supports timing and power-off memory, and is equipped with alarms for overtemperature and probe failure
86-15688870591
sales1@cedriccn.com
Product Features:
·Outer box material: cold-rolled steel plate surface sprayed with plastic; inner material: SUS stainless steel plate.
·GZF-101 top-mounted air outlet is easy to open and close, with a glass inner door and no observation window on the outer door.
·GZF-101 has resistance wire heating at the bottom and a temperature selection switch, which can select the appropriate heating power according to different temperatures.
·GZF-101 fan can be turned off to become a constant temperature drying oven with natural convection.
·GZF-II, GZF-II/H has air inlet and outlet on the back, no glass inner door, and an observation window on the outer door.
·GZF-II, GZF-II/H stainless steel tube ring heater.
·LED digital tube display P.I.D temperature controller, precise temperature control; continuous operation or scheduled operation: 0 ~ 9999min;It has the function of parameter memorization, and the operation will be resumed automatically when the call comes.
Product Specification:
Model | GZF-101-0 | GZF-101-1 | GZF-101-2 | GZF-101-3 | GZF-101-4 | GZF-101-5 |
Temperature range | 50℃ ~300℃ | |||||
Temperature fluctuation | ±1℃ | |||||
Temperature uniformity | ≤ Max operating temperature±2.5% | |||||
Internal circulation method | Forced convection, Bottom heating | |||||
Security alarm | Overtemperature alarm, Temp probe damage alarm | |||||
Internal size (W*D*H, mm) | 350*348*350 | 450*348*450 | 550*448*550 | 600*498*750 | 800*800*1000 | 1000*800*1200 |
Internal volume (L) | 42 | 70 | 135 | 224 | 640 | 960 |
External size (W*D*H, mm) | 677*527*642 | 777*527*742 | 877*627*842 | 927*677*1042 | 1157*975*1290 | 1357*975*1490 |
Packing size(Carton, mm) | 780*640*780 | 870*640*890 | 980*720*990 | 1030*780*1200 | 1480*1100*1480 | |
Weight(kg) | 61 | 74 | 98 | 127 | 305 | |
Shelves | 2 | 2 | 3 | 3 | 3 | 3 |
Power (W) | 1600 | 2400 | 3000 | 4000 | 6000 | 7500 |
Power supply | 1Ø 220V 50Hz | 3Ø 380V 50Hz | ||||
Model | GZF-II-101-0 GZF-II/H-101-0 | GZF-II-101-1 GZF-II/H-101-1 | GZF-II-101-2 GZF-II/H-101-2 | GZF-II-101-3 GZF-II/H-101-3 | GZF-II-101-4 GZF-II/H-101-4 | GZF-II-101-5 GZF-II/H-101-5 |
Temperature range | GZF- Ⅱ： RT+10° C~200° C；GZF- Ⅱ /H： RT+10° C~300° C | |||||
Temperature fluctuation | ±1℃ | |||||
Temperature uniformity | ≤ Max operating temperature±2.5% | |||||
Internal circulation method | Forced convection, Back heating | Forced convection, Bottom heating | ||||
Security alarm | Overtemperature alarm, Temp probe damage alarm | |||||
Internal size (mm) | 350*350*350 | 450*352*450 | 550*454*550 | 600*495*750 | 800*800*1000 | 1000*800*1200 |
Internal volume (L) | 42 | 71 | 137 | 222 | 640 | 960 |
External size (mm) | 635*630*552 | 735*630*652 | 835*730*752 | 885*780*952 | 1157*975*1290 | 1357*975*1490 |
Power (W) | 850(||) 1600(||/H) | 1550(||) 2400(||/H) | 2100(||) 3000(||/H) | 2500(||) 4000(||/H) | 6000 | 7500 |
Power supply | 1Ø 220V 50Hz | 3Ø 380V 50Hz | ||||
