Cleaning

Capacity(L)

220

320

Washer Load Level

2

3

Water Wash Power(kW)

0.75

1.5

Water Heater Power(kW)

5

15

5

15

MAX.Power(kW)

6

16

7

17

Water Consumption/Cycle(L)

20

22

Tank Internal Temperature(℃)

0~99

0~99

Water Supply Pressure(Mpa)

0.3~1.0

Peristaltic Pump for Cleaning Agent

2 independent pumps control detergent agent and neutralizing agent

Cleaning Agent Level Sensor

YES

YES

Washing Pump

Sweden 800L/min

Sweden 1000L/min

Drying

Drying Function

YES

YES

Steam Condenser

YES

YES

Dry Power(kW)

3.6

3.6

Control System

and Traceability

Control System

7"color LCD tou

ch screen display,microprocessor

Cleaning Program

40 pre-set programs (editable)+ 200 PLC free programming

Password Protection

3 levels password

3 levels password

Safety Emergency Button

YES

YES

USB port

YES

YES

Integrated printer

Optional

Optional

Online Monitor Performance of Washing

Optional

Optional

Dimensions &Weight

Chamber Size(W*D*H,mm)

600*629*754

600*629*915

Exterior Size(W*D*H,mm)

695*870*1820

695*870*1990

Package Size(W*D*H,mm)

810*990*2015

810*990*2185

Net Weight(Host only,kg)

220

237

Gross Weight(Host with rack,kg)

300

320

Others

Door

Double-layered Glass Door

Double-layered Glass Door

Safety Door Lock

YES

YES

Built-in RO Water Pump

YES

YES

Noise(dBa)

<55

<55

Voltage(V/Hz)

220V~240V/ 50~60Hz

380V/

50~60Hz

220V~240V/ 50~60Hz

380V/

50~60Hz
